quote:
ORIGINAL: Dutchie999 new K-77M (izdeliye 180) citation from report by the designer of "GosMKB "Vympel" I.I. Toropova" G.A. Sokolovsky at the Jubilee Scientific Conference "Aviation systems in the XXI Century" : "In the field of medium-range weapons are the modernization of the P-77. Improved version of the first missile was 170-1. The next stage of modernization - izd. 180. Lattice rudders will be replaced by non-folding flat handlebars. Rocket is planned to equip the new multi-mode active-passive seeker. Passive mode will allow homing on sources emitting radar and enemy aircraft." http://take-off.ru/pdf/05_2006.pdf Page 35-36 in russian and about other PAK-FA weapons: "It also creates a virtually new short-range missiles, short-range air combat and highly maneuverable missile defense, designated K-MD ("article 300"). The missile is equipped with a matrix of thermal seeker with the ability to pattern recognition and increased twofold range of capture. Engine with dual-mode operation time up to 100 seconds and three-channel device gasdynamic control. Missile tests were expected in 2014-2015. A separate area of the family of missiles R-77 is to provide a "product- 180PD" extended range, and missiles with index "181C" In the area of long-range weapons "Vympel" performs work on the modernization of the R-37, R & D "MFBU-810." As part of the pilot project on a competitive basis based on izd. 610M developed new izd. 810. This missile should be placed in the inner compartments. Range increased by 1.5 times, altitude targets up to 40 km. Operating time power unit - 360 sec." From interview with director of the KTRV Boris Obnosov : "...Demonstrate this time on air saloon missile RVV-MD and RVV-SD, according to Boris Obnosov as intended means for external suspension, but, are essentially prototypes based on which by 2014 will be created improved samples for PAK FA. They will form the basis of his weapon in class missiles "air-air" close combat and medium range. Presented at the MAKS-2011 antiradiolokation missile X-58USHKE (developer - GosMKB "Raduga") pre- designated as external and for internal placement. she has a mass of 650 kg and a launch range 76-245 km . From known for years X-58E it is less in length, presence folding wings and rudders less scope and application of the single broad way passive radar head , which captures all known station air defense. on the big screen on the stand KTRV at MAKS-2011 demonstrated an animated video video, which can be seen as will host four missiles similar tion type in the inner compartments plane of fifth generation(PAK-FA). State tests X-58USHKE, according to Mr. Obnosov, scheduled to be completed next year. Another Missile that will go down in the armed fighter of the fifth generation and can be placed in inner compartments - modular multipurpose missile "air-surface" of the new Generation X-38ME launch weight up 520 kg with a range of up to 40 km, the appointed to defeat the general range of armored, durable or very vulnerable surface singles and group objects, and Sea objects. On previous Show in Zhukovsky, when the debut of a family of Kh-38ME (the developer - the parent enterprise Corporation "Tactical Missile Armament" , it is reported that they could equipped with different systems Guidance: semi-active laser homing (X-38MLE), ARH(X-38MAE), television seeker(X-38MTE) and satellite system guidance (X-38MKE battle with cassette part). At MAKS 2011 demonstriro- valas "laser" missile X-38MLE. According to Boris Obnosov, works on her creation goes according to plan, their completion is expected in a couple of years. The novelty of this air show has become Guided bombs caliber 250kg type KAB-250 (development of SSPE "Region") which, thanks to its compact size , can be placed not only on various external sling carriers , but also in the inner compartments PAK FA. "Guided bombs that caliber so far we have not had - said at a press conference during the MAKS-2011 Boris Portages. - KAB-250 - weapons inner fuselage placement for the PAK FA, but can also be used by other aircraft. "At the air show were only the basic parameters of the new 250-kg bomb: length - 3.2 m, case diameter - 255 mm, wingspan - 550 mm. "A more detailed talk about the characteristics of KAB-250 is still too early, "- said Mr. Obnosov. Not been reported so far and the type of its guidance. However, the head of the Tactical Missiles Corporation, speaking of applying for guidance GPS and GLONASS receivers stated that "such bombs already in the cali- ber of 500 kg (meaning KAB-500S-E) Satellite navigation is provided and almost all the bombs next generation in the class 1500, 500 and 250 kg ". Thus, it is logical to conclude that KAB-250 will have a combined guidance system, comprising conductive inertial-satellite system and one of the homing head." http://take-off.ru/pdf/10_2011.pdf page 37-38 in russian according to patent for KAB-250 guidance system GLONASS+INS and "...thermal imaging seeker in the far infrared range 8-14 µm". http://www.findpatent.ru/patent/233/2339905.html in russian From report by the designer of "GosMKB "Vympel" I.I. Toropova" G.A. Sokolovsky at the Jubilee Scientific Conference "Aviation systems in the XXI Century": "Internal compartments are equipped with devices for catapult launching missiles UVKU-50L (for missiles weighing up to 300 kg) and UVKU-50U missile weighing up to 700 kg". In main bays can be installed UVKU-50U or UVKU-50L UVKU-50L and UVKU-50U can be "left" and "right"(no "center" variant so I think it is 2x2=4 inner points for weapons in main bays + 2 short range missiles in "fast" bays) weapons for UVKU-50L is: izd 180(RVV-SD upgrade), izd 180PD (izd 180 with ramjet), izd 270 (future long range AAM on base of izd 180), izd 181S , izd. K047(KAB-250) for UVKU-50U is: izd 65 (Kh-38),izd. D7UShK(Kh-58UShK),izd 810(AA-13 [R-37M] in database) http://forumimage.ru/uploads/20110922/131670317039002348.jpg from "UVKU-50U maintenance manual" http://www.mycity-military.com/thumbs2/139754_tmb_189912987_UVKU-50L%201.jpg "UVKU-50L maintenance manual" http://www.mycity-military.com/imgs2/139754_265878174_UVKU-50L.jpg "UVKU-50L maintenance manual" http://cs9733.userapi.com/u4006000/120803604/z_9bb15103.jpg - "UVKU-50L maintenance manual" http://vk.com/video-14964099_161020193 video UVKU-50L in work http://webcache.googleusercontent.com/search?q=cache:D2bRCz-ypyoJ:www.freepatent.ru/patents/2381146+&cd=3&hl=ru&ct=clnk&gl=ru Patent for UVKU-50 in russian Other weapon,like Kh-31PD,Kh-35U etc. on external So can you please: - Add some (or even all) variants of Kh-38 in database http://eng.ktrv.ru/production_eng/323/513/537/ - Add Kh-58UShK in database http://eng.ktrv.ru/production_eng/323/511/540/ - Add KAB-250 in database - and create loadouts with this missiles and bomb for PAK-FA
< Message edited by Triode -- 10/29/2014 5:08:41 AM >
|
